01 – Hero
H1: Acoustic Glass for Meeting Pods
Subheading: High-Performance Acoustic Glazing for Meeting Pods, Huddle Rooms & Small Conference Enclosures
Key Specs Badge: STC 42–50 ｜ Acoustic Laminated / IGU / Composite ｜ Tempered Safety ｜ CNC Cut-outs ｜ OEM
CTA Buttons: [Request a Quote] [Send Your Glass Specification]
02 – Application Definition
H2: What Is Meeting Pod Acoustic Glass?
Meeting pods are enclosed collaboration spaces within open-plan offices, designed to host 2–6 people for confidential discussions, video calls, and workshops. Unlike single-user focus booths, meeting pods have larger glazed areas, wider door leaves, and higher speech-energy load—making sound leakage more critical. Meeting Pod Acoustic Glass refers to the engineered glass panels and door leaves that deliver speech privacy in both directions (voice in / voice out) while preserving visual openness and natural light. The glass must balance acoustic rating, safety, hardware integration, and aesthetic alignment with brand-led pod designs.
03 – Acoustic Requirements
H2: Acoustic Requirements for Meeting Pods
| Requirement | Why It Matters in Meeting Pods |
|---|
| Speech Privacy (both ways) | Confidential HR/client talks must not leak to open office |
| Higher STC Target | 2–6 voices + video call audio = higher sound energy than solo pod |
| Larger Glazed Area | More glass = more flanking risk; panel STC must compensate |
| Wider Door Leaf | Door is weakest link; acoustic door glass + drop seal mandatory |
| Display/Power Cut-outs | Screens, power modules require precise CNC holes without breaking acoustic seal |
| Safety | Tempered + laminated for commercial occupancy codes |
| Framing Compatibility | Must seat into aluminum/steel profiles with acoustic gaskets |
04 – Recommended Glass Solutions (Glass Selection 独家模块)
H2: Recommended Acoustic Glass for Meeting Pods
| Glass Solution | Typical Structure | Indicative STC* | Meeting Pod Use |
|---|
| Acoustic Laminated Glass | 6T + 1.14 PVB + 6T | STC 41–43 | Standard 2–3 person pod |
| Acoustic Laminated Glass | 8T + 1.52 PVB + 8T | STC 43–45 | 4–6 person pod wall |
| Acoustic Insulated Glass | 6T + 16Ar + 8T | STC 43–46 | Enhanced privacy, thermal control |
| Acoustic Laminated Insulated | 6T+1.14PVB+6T + 16Ar + 8T | STC 47–50 | Executive / boardroom pod |
| Custom Composite | Project-specific | Specified | OEM high-end systems
*Indicative glass-only rating. Final pod ASTC depends on frame, seals, door, and installation (ASTM E90 / ISO 10140 for glass; ISO 23351 for complete pod).
内部链接（锚文本 → Products 页）： |
05 – Glass Structure Diagram
H2: Typical Glass Build-Ups for Meeting Pods
Standard Wall (Most Common):
6 mm Tempered Glass
↓
Acoustic PVB Interlayer (1.14 mm)
↓
6 mm Tempered Glass
→ STC 41–43, 12 mm overall, easy hardware integration
High-Performance Wall (IGU Option):
6 mm Tempered Glass
↓
16 mm Argon Cavity (warm-edge spacer)
↓
8 mm Tempered Glass
→ STC 43–46, thermal + acoustic, 30 mm overall
Executive / Boardroom Wall (Composite):
6T + 1.14 Acoustic PVB + 6T
↓
16 mm Argon Cavity
↓
8T
→ STC 47–50, best-in-class speech privacy
Door Leaf (matched): 6T + 1.14 PVB + 6T with CNC hinge cut-outs, lock borehole, drop-seal channel.
06 – Acoustic Performance & Testing
H2: Acoustic Performance
- Glass-only STC: 41–50 (by configuration)
- Rw (EN ISO 717-1): up to 47 dB
- Frequency tuning: Acoustic PVB targets 1000–4000 Hz speech band
- Asymmetry principle: Different pane thicknesses (6+8) shift coincidence dip away from speech range
- Test standards: ASTM E90 / E413, EN ISO 10140 (glass); ISO 23351-1 (complete pod speech level reduction)
- Field note: Glass STC is necessary but not sufficient—pod ASTC drops 3–5 pts if frame seals are weak. We provide calculation support, not just glass.
07 – Specifications
H2: Meeting Pod Glass Specifications
| Parameter | Available Options |
|---|
| Glass Type | Tempered Laminated / IGU / Composite |
| Pane Thickness | 5 / 6 / 8 / 10 mm per lite |
| Overall Thickness | 12 mm – 38 mm |
| Interlayer | Acoustic PVB 0.76 / 1.14 / 1.52 mm, SGP optional |
| Cavity | 12 / 16 / 20 mm, Argon 90% |
| Max Panel Size | 2440 × 5000 mm (jumbo line) |
| Door Max Size | 1000 × 2400 mm |
| VLT | 80–90% clear, ~91% Low-Iron |
| Surface | Clear / Frosted band / Silk-screen logo |
| CNC | Hinge holes, lock boreholes, closer mounts, display/power cut-outs |
| Compliance | EN 12150, EN 14449, ANSI Z97.1, CE, UKCA |
08 – Integration With Meeting Pod System
H2: Acoustic Glass Integration for Meeting Pods
Meeting pod glazing performs only as well as its weakest junction. Our glass is engineered to integrate with:
- Aluminum frame systems – standard pod extrusion profiles, EPDM acoustic gaskets
- Steel frame systems – heavy-duty commercial enclosures
- Frameless structural silicone – minimalist glass-to-glass corners
- Acoustic door kit – matched laminated door leaf + drop seal + perimeter compression gasket
- Hardware templates – Assa Abloy, Dormakaba, GEZE hinge/lock/closer cut-outs (±0.5 mm)
- Service cut-outs – screen mount holes, power/grommet openings with acoustic plug recommendations
- Ceiling/floor transition – glass stops short of hard flanking paths; recommend acoustic break at head/jamb
09 – Customization for Meeting Pod OEMs
H2: Custom Acoustic Glass for Meeting Pod Manufacturers
- Build-to-target STC – send us your pod ASTC goal, we reverse-engineer glass build-up
- Brand aesthetics – Low-Iron ultra-clear, tinted, silk-screen logo band, frosted manifest line
- Door engineering – hinge style (pivot/concealed/butt), lock type, closer model, finger-pull routing
- Display integration – HDMI/power grommet holes, camera shelf notch
- Modular sizing – standard 900×2100 door, 1200×2400 wall panel, or your DXF
- Private label – crate labeling, spec-sheet co-branding, HS code support
- Prototype lead time – 10–14 days for sample panel + door leaf
10 – Manufacturing & Quality
H2: Manufactured for Global Meeting Pod Brands
- 20+ years tempered / laminated / IGU export manufacturing
- Dedicated acoustic line – separate PVB laminating room, humidity-controlled IGU chamber
- Jumbo tempering – up to 2440 × 5000 mm, flatness ≤ 0.3%
- CNC machining center – hinge/lock/cut-out tolerance ±0.5 mm
- QC per batch – 100% spark test, dimensional laser scan, sample STC audit
- Export crating – fumigated wood, EVA edge guard, vertical dividers, shock label
- Served office pod OEMs in EU, UK, US, AU, UAE
11 – Testing & Compliance
H2: Testing & Standards
- Glass acoustic: ASTM E90, EN ISO 10140-1/2 (transmission loss)
- Safety glass: EN 12150 (tempered), EN 14449 (laminated), ANSI Z97.1, AS/NZS 2208
- IGU durability: EN 1279-1~4
- Factory: ISO 9001:2015
- Third-party: SGS / Intertek on request
- Pod-level reference: Glass solutions engineered for meeting pods evaluated under ISO 23351-1 (speech level reduction) — not a glass certificate, stated accurately
12 – FAQ
H2: Frequently Asked Questions
- What STC should a meeting pod glass have?
For 2–4 person pods, STC 42–45 glass is typical; 4–6 person or confidential-use pods target STC 47–50 with composite build. - Is laminated glass enough for a meeting pod?
For standard pods yes (6+1.14PVB+6 ≈ STC 42). For executive pods, add IGU cavity or go composite. - Can the door reach the same STC as the wall?
Yes—matched laminated door leaf + acoustic drop seal + framed perimeter gasket can close the gap to within 2–3 STC points. - Can you machine holes for screen and power?
Yes, CNC cut-outs for grommets, HDMI plates, and camera shelves; we advise acoustic plug detailing to avoid leaks. - Do you supply Low-Iron for premium pods?
Yes, Low-Iron acoustic laminated glass reaches ~91% VLT, common in brand-led executive pods. - Can glass-only STC be guaranteed for the whole pod?
No—only glass STC is certifiable per ASTM E90. Pod ASTC depends on your frame/seal assembly; we provide calculation support. - What is the max panel size?
2440 × 5000 mm jumbo; typical pod wall panel 1200 × 2400 mm. - Can you match our hardware template?
Yes, send DWG/DXF with hinge/lock/closer centers; we machine to ±0.5 mm. - Lead time for OEM order?
Samples 10–14 days; bulk 25–35 days FOB depending on mix. - Do you provide test reports?
Yes—lab STC report for the specified glass build-up + calculation note for complete system.
Final CTA
H2: Need Acoustic Glass for Your Meeting Pod?
Send your pod drawing, target STC, or hardware template. Our engineering team recommends the optimal glass build-up and quotes per project.
[Request a Quote] [Send Your Drawing] [Download Acoustic Glass Datasheet]
