01 Acoustic Glass Doors
Subheading: High-Performance Soundproof Glass Doors for Office Pods, Meeting Rooms & Architectural Partitions
Key Specs Badge: STC 35–45 ｜ Acoustic Laminated & Insulated ｜ OEM Sizes ｜ Hardware Cut-outs ｜ CE / ASTM
CTA Buttons: [Request a Quote] [Download Datasheet]
02 – Product Definition (What Is It?)
H2: What Are Acoustic Glass Doors?
Acoustic Glass Doors are specialized door systems engineered with high-performance soundproof glass to provide privacy and noise isolation in modular office pods, meeting rooms, and interior partitions. Unlike standard glass doors, these doors use acoustic laminated or insulated glass constructions, combined with precision hardware integration (hinges, locks, closers) and perimeter sealing, to achieve measurable STC ratings. They are designed as a drop-in component for pod manufacturers and architectural projects, ensuring both acoustic performance and safe, reliable operation.
(Word count: ~80 – 30 秒可读完)
03 – Glass Structure
H2: Glass Structure & Composition
Acoustic Glass Doors can be configured with two main glass structures, depending on the required acoustic and safety performance:
Option A: Acoustic Laminated Glass (Most Common for Doors)
6 mm Tempered Glass
↓
Acoustic PVB Interlayer (0.76 mm / 1.14 mm / 1.52 mm)
↓
6 mm Tempered Glass
Overall thickness: ~12 mm – 16 mm. Ideal for single-door pods and booths.
Option B: Acoustic Insulated Glass (Enhanced Performance)
6 mm Tempered Glass
↓
16 mm Argon Cavity
↓
8 mm Tempered Glass
Overall thickness: ~30 mm. Used in high-end meeting pods and executive spaces.
Key Structural Elements:
- Glass: Fully tempered, heat-soaked optional
- Interlayer: Acoustic PVB (standard), SGP (on request)
- Cavity: Argon-filled for IGU options
- Safety: Laminated glass remains intact upon breakage; tempered glass for impact resistance
- Edgework: Polished edges for safe handling and hardware mounting
04 – Available Configurations
H2: Available Configurations
| Configuration | Overall Thickness | Typical Acoustic Target (Indicative*) | Typical Application |
|---|
| 6 + Acoustic PVB + 6 | ~12 mm | STC 35–38 | Phone Booth Door |
| 8 + Acoustic PVB + 8 | ~16 mm | STC 39–42 | Office Pod Door |
| 6 + 16Ar + 8 (IGU) | ~30 mm | STC 42–45 | Meeting Pod Door |
| 6 + PVB + 6 + 16Ar + 8 (Laminated IGU) | ~38 mm | STC 45–48 | Executive Pod Door |
| Custom | Project-specific | Project-specific | OEM Door Systems
*Acoustic performance is indicative and depends on complete door system design, including frame, sealing, hinges, and installation. Test reports available upon request. |
05 – Acoustic Performance
H2: Acoustic Performance
- Sound Transmission Class (STC): 35 – 45 (depending on glass configuration and door sealing)
- Weighted Sound Reduction Index (Rw): Up to 43 dB
- Frequency Range: Optimized for 500 Hz – 4000 Hz (speech frequencies)
- Test Standards: ASTM E90, EN ISO 10140, ISO 717-1
- Performance Data: Available in downloadable datasheet (includes lab-tested reports for specific door builds)
06 – Safety Performance
H2: Safety & Impact Performance
- Impact Safety: Classified as Class A / Class B (EN 12600), ANSI Z97.1 Category II
- Post-Breakage Behavior: Laminated glass fragments remain bonded to the PVB interlayer, preventing shattering and fall-out—critical for door applications
- Tempered Glass: Heat-treated for 4–5x strength vs. annealed glass
- Optional Heat Soak Test: According to EN 14179-1 to minimize spontaneous breakage
- Hinge & Hardware Load: Glass prepared with CNC cut-outs to withstand door hardware stress
- Compliance: Meets CE, UKCA, and ANSI standards for safety glass doors
07 – Specifications
H2: Technical Specifications
| Parameter | Details |
|---|
| Glass Type | Fully Tempered / Heat-Strengthened (optional) |
| Interlayer | Acoustic PVB (standard), SGP (on request) |
| Overall Thickness | 12 mm – 38 mm |
| Max Door Panel Size | Up to 1200 mm × 2400 mm (custom jumbo on request) |
| Visible Light Transmittance (VLT) | 80% – 90% (clear), custom with Low-Iron |
| Edgework | Polished / Grinded / CNC machined |
| Processing | CNC cutting, waterjet, hinge cut-outs, lock boreholes, silk screen, frosted |
08 – Applications
H2: Typical Applications
- Office Pods – Single-user focus pods requiring STC 35+ privacy (link → Applications/Office Pods)
- Phone Booths – Compact acoustic cabins for private calls (link → Applications/Phone Booths)
- Meeting Pods – Small to medium conference spaces with high speech intelligibility (link → Applications/Meeting Pods)
- Acoustic Work Pods – Collaborative work booths (link → Applications/Acoustic Work Pods)
- Recording Booths – Voice-over and podcast studios (link → Applications/Recording Booths)
- Architectural Partitions – Interior glazed doors in open-plan offices
09 – Customization
H2: Customization & OEM Options
We manufacture door glass panels to your exact specification. Our acoustic glass doors support:
- Custom Thickness: Tailored glass + interlayer combinations for your door design
- Custom Dimensions: Cut to size, including oversized panels for grand entrances
- CNC Processing: Precision hinge cut-outs, lock boreholes, closer mounts, and handle holes
- Surface Treatments: Silk screen printing, frosted acid-etch, digital ceramic frit for branding or privacy
- Glass Options: Low-Iron (ultra-clear), tinted, reflective
- OEM Packaging: Export-standard wooden crates with foam protection, custom labeling for door panels
- Hardware Compatibility: We work with your hardware supplier’s templates (Assa Abloy, Dormakaba, etc.)
10 – Testing & Certifications
H2: Testing & Certifications
- Acoustic Testing: ASTM E90, EN ISO 10140 series
- Safety Glass: CE Marking (EN 14449), UKCA, ANSI Z97.1, AS/NZS 2208
- Factory Certification: ISO 9001:2015 Quality Management System
- Third-Party Verification: SGS, Intertek, or equivalent (on request)
- Document Package: Test reports, declarations of performance, and compliance certificates provided with every shipment
11 – Manufacturing Capability
H2: Why Source From Us?
- 20+ Years in tempered and laminated glass manufacturing
- Dedicated Acoustic Production Line – separate from standard glass to avoid cross-contamination
- Precision CNC Processing – for hinge and lock cut-outs with ±0.5 mm tolerance
- Jumbo Glass Capability – maximum 2440 × 5000 mm for large door panels
- In-House Acoustic R&D – we don't just trade; we engineer
- Export Experience – served 30+ countries, familiar with Incoterms, ocean freight packaging, and customs documentation
- Fast Sampling – prototype door glass ready in 7–10 days
12 – RFQ (Request for Quotation)
H2: Send Your Door Glass Specification
Ready to get pricing for your acoustic glass door project?
Please provide:
- Glass structure (e.g., 6 mm + 1.14 mm PVB + 6 mm)
- Door panel dimensions (W × H, quantity)
- Acoustic target (STC or Rw if specified)
- Hardware requirements (hinge type, lock borehole size, closer)
- Processing requirements (edgework, surface treatment)
- Delivery destination & Incoterm
- 📩 Email: tomron1688@gmail.com
- [Request a Quote] [Download Datasheet]
