1. Product Definition
Anti-Smash Glass with "tempered glass + flexible interlayer + polycarbonate" structure:
✅ Energy Absorption: Outer glass shatters to dissipate force
✅ Fragment Retention: PVB/SGP interlayer traps debris
✅ Penetration Barrier: PC inner layer blocks tools (※demo video)
Core Tech: Kuraray SGP ionoplast (35MPa tear strength) + anti-pry frame
2. Technical Specifications
| Protection Class | Impact Resistance | Delay Time | Thickness | VLT | Standard |
|---|
| EN356 P5A | 50J | >10 min | 0.47-0.7" | ≥88% | EN356:2020 |
| EN356 P8A | 120J | >30 min | 1.2-1.5" | ≥83% | EN356:2020 |
| UL972 BR4 | 200ft-lb | >20 min | 1-1.25" | ≥85% | UL972 |
| Jewelry Cabinet Grade | 150J | >45 min | 1.8-2" | ≥78% | ISO 21934 |
※P8A = withstands 10lb hammer drop from 4ft height
3. Engineering Capabilities
| Parameter | Industry Max | Our Spec | Technology |
|---|
| Max Size | 94"×47" | 118"×71" | Bystronic lamination (±0.012") |
| Min Thickness | 0.6" | 0.47" (P5A) | Nano-tempered technology |
| Light Transmission | 75% | 88% (P5A) | Optical-grade PC substrate |
| Frame System | Aluminum | Stealth Ti-frame | Tri-point locks + micro-sensors |
4. Five Competitive Advantages
1. Certified Performance
Met Police Test: 28min against HILTI TE60 drill (3 bits worn)
2. Scenario Solutions
| High-Risk Site | Solution | Security Features |
|---|
| Luxury boutiques | Ultra-clear display | 92% VLT |
| Prison visitor rooms | Double-sided barrier | Mohs hardness ≥8 |
| Embassy windows | Hidden frame + auto-lock | 0.3s emergency seal |
3. Visual Stealth
- Anti-reflective coating (≤6% reflectivity)
- Haze ≤0.5%
4. Smart Integration
- Micro-pressure sensors (detects 2.2lbf prying)
- 5G alarm system integration
5. Global Projects
| Project | Country | Solution | Security Performance |
|---|
| Hatton Garden Jewelers | UK | P8A invisible case | 18min oxy-fuel resistance |
| Dubai Gold Souk | UAE | Laminated curtain wall | EN356 P8A + blast film |
| Tiffany Fifth Avenue | USA | Jewelry cabinet grade | No crack at 150J impact |
6. Why Global Security Firms Choose Us?
✅ TÜV Certified: Full EN356 P1A-P8A certification
✅ Triple Guarantee:10-year anti-intrusion warrantyLifetime anti-pry structure warrantyFree annual security audit
✅ Global Rapid Response: 24/7 support in 48 countries
✅ System Integration: Free security system design
❗ First Order Exclusive: Free Smart Security Kit ($800 value)
![]()
